Beyond the barcode

Scanning technology is moving far beyond the laser-scanned barcodes you’ve become familiar with at grocery stores, gyms, and concerts. In fact, you’re likely using or benefiting from next-generation RFID and QR codes right now. The NFL used RFID in 2015 to provide what it calls “Next Gen Stats” for every player on the field.¹ Your own business could be using this scanning technology to boost your bottom line, attract customers, control inventory, and more.

While RFID, QR codes, and barcodes are all ways to communicate information in a way that machines can quickly and easily understand, there are key differences between each. Here’s what these technologies are, how they work, and how you can take advantage of them.

What’s the difference: Barcode, QR code, and RFID?

	Barcode	QR Code	RFID
Most commonly used for	Inventory control	Advertising website URLs	Automated inventory management
Interesting uses includes	Barcodes as input into video games, event registration	Virtual store with codes by pictures of sale items, links on building permits	Interactive experiences at sporting events and festivals, pet tracking/identification tags
Needs to be visible (line of sight for the scanner)*	Yes	No	No
Range for reading by the scanner*	Several inches to a foot	Several inches to a foot	Up to 30 feet (“Passive” tags), up to 100s of feet (“Active” tags)
Read/Write capability*	Read only	Read only	Read and write (data can be changed on tag)
Data capacity*	Less than 20 characters	7,089 characters	Thousands of characters
Reliability/ ruggedness*	Wrinkled tags won’t work	Up to 30% recovery of data from wrinkled codes	Very reliable
Marginal cost (cost per tag)*	$0.01	$0.05	$0.05 to $1.00

Barcodes

Barcodes are a kind of machine-readable text, with each number from zero to nine represented by a pattern of black and white lines. For example, the number one is represented by a thick white stripe, a thick black stripe, a thin white stripe, and a thin black stripe. You can think of barcodes as Morse code for computers. When a laser scans the series of lines, the black lines absorb more light, telling the scanner what numbers are represented. The very first barcode was introduced in 1974 on a pack of Wrigley’s Juicy Fruit gum,² and barcodes have only grown in popularity from there.

• How barcodes can help your business: 48% of small businesses do not track their inventory or use a manual process.³ Barcodes can be a low-cost and efficient way to manage your inventory, helping reduce errors and improve your cash flow.

QR (Quick Response) codes

You can think of QR codes as an expansion of barcodes where both the vertical and horizontal placement of black dots are read by an optical scanner. This expansion from one dimension to two allows for characters as well as numbers to be encoded in QR codes—and means about 100 times more data can be stored on them. The first QR code was used within the car manufacturing industry in Japan in 1994, and expanded to the public from there in parallel with the growing popularity of smartphones capable of scanning them.⁴

• How QR codes can help your business: Websites are the second most popular marketing tool used by small businesses.³ QR codes can be an effective and inexpensive way to drive new traffic to your website, boosting the effectiveness of both your online and print marketing efforts.

RFID (Radio-Frequency Identification)

If barcodes are in a sense one-dimensional data, and QR codes are two-dimensional, than you can think of RFID tags as a three-dimensional code. Instead of laser scanners for barcodes and optical scanners for QR codes, RFID tags use radio waves to transmit the information stored in them. Because of this, RFID scanners don’t need to directly see the tags (have line-of-sight). Instead, they simply need to be in close proximity to the tags. A good example of this is when you use a wireless toll payment system in your car. Thanks to the ease of scanning RFID tags, they allow for more flexibility and automation in inventory management. Modern tags can even be as small as a grain of rice.⁵

• How RFID tags can help your business: While barcodes and QR codes are often less expensive than RFID, there are a number of cases where RFID may provide a better ROI. For instance, in RFID the data can be encrypted to provide enhanced security, the tags can store much more data than other methods, and RFID tags can be read all at once, rather than one at a time, by the scanner.

New applications for scanning technology are being introduced all the time. ;HP Proximity Card Readers read RFID tags in an employee’s security card to protect confidential documents by releasing print jobs only to the right user. Building permits in New York City are now required to use QR codes that provide additional information about the project.⁶ And barcodes have never wavered in their popularity, even becoming something of an artform. But no matter what use you have for scanning technology, the companies that take advantage of any of its forms have a clear advantage over those that don’t. Now that you’ve learned the basics, what will your company do next?
